| AC arc welding machine: BX1-200-1 |
| Features: |
| 1. Single phase moving core type and forced air cooling structure. |
| 2. Suitable for welding ferrous metal workpiece with general AC electrode. |
| 3. Stable arc, less spatter and deep penetration can ensure welding quality well. |
| 4. Simple structure, high efficiency, easy to operate and maintenance. |
| 5. Fit with fast connectors |
|
Item |
BX1-160-1 |
BX1-200-1 |
BX1-250-1 |
BX1-315-1 |
BX1-400-1 |
BX1-500-1 |
BX1-630-1 |
|
Rated output current(A) |
160 |
200 |
250 |
315 |
400 |
500 |
630 |
|
Power voltage(V) |
230/400 |
230/400 |
230/400 |
230/400 |
230/400 |
230/400 |
230/400 |
|
Rated duty cycle(%) |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
|
Rated input capacity(KVA) |
9.2 |
13.2 |
16.5 |
24 |
33.4 |
41.8 |
52.6 |
|
Current adjustable range(A) |
40-160 |
45-200 |
50-250 |
60-315 |
80-400 |
100-500 |
125-630 |
|
Insulation grade |
F |
F |
F |
F |
F |
F |
F |
|
No-load voltage(V) |
55 |
55 |
55 |
60 |
70 |
76 |
76 |
|
Weight(KG) |
59 |
59 |
60 |
66 |
77 |
95 |
100 |
|
Measurement(MM) |
600x430x610 |
650x455x645 |
650x455x690 |
680x500x690 |
680x500x690 |
800x530x750 |
800x530x760 |
|
Usable electrode(MM) |
1.6~3.2 |
1.6~4 |
2.5~5 |
2.5~5 |
2.5~6 |
2.5~8 |
2.5~10 | |
